304L Stainless Steel Pipe Description

304L stainless steel pipe is a variant of 304 stainless steel pipe with a lower carbon content and is often used in welding scenarios. The lower carbon content greatly reduces the precipitation of carbides in the heat-affected zone close to the weld, and the precipitation of carbides is associated with intergranular corrosion of stainless steel in certain environments. Basically, the need to anneal weld joints prior to using the completed metal form is not needed using 304L, saving time and effort. Generally speaking, both 304 and 304L stainless steel plates can be used for many of the same applications. The differences are often not significant enough that one is considered more useful over the other. 304L stainless steel plate is more commonly used in fields such as food processing equipment, building materials, automobile parts.


Product Parameters

Product Name

304L Stainless Steel Pipe

Type

Steel Pipe

Outer diameter

Round Tube

4mm-200mm

Square Tube

10*10mm-100*100mm

Rectangular Tube

10*20mm-50*100mm

Wall Thickness

0.6mm-6.0mm

Length

1-6 meters, Length can be customized

Standard

ASTM, AISI, JIS, GB, DIN, EN, etc.

Surface

Black, Bright Polished, Rough Turning, Matt Surface Treatment, No. 4. BA, etc.

Scope of Application

Common applications for stainless steel pipes include food processing,

Textile operations, Breweries, Water treatment plants, Oil and gas processing,

Fertilizers and pesticides, Chemical applications, Construction, Pharmaceuticals, Auto parts, etc.

Certificate

ISO, SGS, BV, etc.

Production Technology

Hot Rolling, Cold Rolling

Edge Processing

Edging, Trimming


Chemical Composition

C

Si

Mn

Cr

Ni

S

P

≤ 0.03

≤1.0

≤ 2.0

18.0~20.0

8.0~12.0

≤ 0.03

≤ 0.035


Mechanical Properties

Tensile Strength Kb (MPa)

Yield Strength σ0.2 (MPa)

Elongation D5 (%)

Hardness

≥ 520

≥ 205

≥ 40

≤ 187HB ;≤ 90HRB;≤ 200HV


Physical Performance

Density(g/cm³)

Modulus of Elasticity(Gpa)

Coefficient of Thermal Expansion(10-6/°C)

Coefficient of Thermal Conductivity(W/m*K)

Resistivity(ΜΩ. cm)

8.03

193

16.9

16.2

72
